MID-CONTINENT TRUE BLUE DUAL USB CHARGING PORT TA102 FAA-TSO

79 500
Описание
The self-contained TA102 Dual USB Charging Port is a modern addition to any cockpit and interior cabin. Each USB port is designed to supply the electric current needed to charge any standard or high-power device with a USB interface.
  • Cell Phones
  • Tablets
  • GPS devices
The TA102 protects itself and the charging device from short-circuit, power surges and over-current potential.

Application:
    Intended for Cock-pit & Cabin for most GA aircraft up to Boeing 777
Features
  • Output Power: 2.1 amps per port
  • Input Voltage: 10 – 32 VDC
  • Output Voltage: 5 VDC ± 0.25 per port
  • Charge one or two products simultaneously with a USB interface
  • Short-circuit, over-current, and over-temperature protection
  • Panel or cabin mount
Eligibilities

Warranty

LIMITED LIFETIME WARRANTY
This limited lifetime warranty is extended by True Blue Power, a division of Mid-Continent Instrument Co., Inc. to all ultimate and direct purchasers of specific True Blue Power products covered herein.

True Blue Power warrants specific products manufactured by Mid-Continent Instrument Co., Inc. to be free from defects in material and workmanship when installed and used under recommended conditions and to perform according to the requirements of their individual specifications. This limited lifetime warranty applies ONLY to the original installation and non-commercial applications (Part 121 & 125, and is effective only after product registration card has been completed within 45 days of purchase.

The following situations will not be covered under this limited warranty:
  • Any defect, malfunction, breakage, or failure caused by unreasonable use or abuse while in the possession of a buyer.
  • Any defect, malfunction, breakage, or failure caused by mis-wiring at installation by the customer or his/her agent.
  • No product will be eligible for warranty consideration if, subsequent to its delivery, an alteration or modification becomes necessary for product improvement or in order to meet a change in the requirements of any applicable federal regulation.
  • Cosmetic damage, including but not limited to scratches, dents and broken plastic on ports
If any listed True Blue Power component fails within the duration of the express warranty, the entire extent of the Mid-Continent Instrument Co., Inc. liability under this warranty is limited to repair or replacement, at True Blue Power’s option. Eligible products shall be returned directly to True Blue Power, properly packaged and postage prepaid.

Examination must disclose a valid warranty condition to the satisfaction of True Blue Power.

In no event will seller be liable for any incidental damages, consequential damages, special damages, indirect damages, loss of profits, loss of revenues, or loss of use, even if informed of the possibility of such damages. Seller’s liability for damages arising out of, or correlating to a product or an order, is limited to the lesser of catalog or contract price for the specific product that gives rise to the claim. To the extent permitted by applicable law, these limitations and exclusions will apply regardless of whether liability arises from breach of contract, warranty, tort (including but not limited to negligence), by operation or law, or otherwise.

Printable Warranty (PDF)
Арт. MPN Описание Цена Add to cart form
11-13094
6430102-4
MCI TRUE BLUE DUAL LIT USB CHARGING PORT BOTTOM CONNECTOR
$ 285
11-13093
6430102-2
MCI TRUE BLUE DUAL USB CHARGING PORT BOTTOM CONNECTOR TA102
$ 265
11-13044
6430102-3
MCI TRUE BLUE DUAL USB CHARGING PORT LIGHTED TA102-3
$ 285
11-12159
6430102-1
MID-CONTINENT TRUE BLUE DUAL USB CHARGING PORT TA102 FAA-TSO
$ 265

Отзывы Оставить отзыв

Отзывы ещё не добавлены

Вопросы и ответы
Can I use a KGS LT-71A to power this unit? I currently have a KGS LT-71A installed supplying power to a round 14v 4 amp outlet socket. I would like to replace the socket with this unit if possible.

Per the supplier: Our unit is dual voltage 10-32 volts. You can use it with your KGS LT-71A.

Does this True Blue Dual USB charging port FAA Approved?

Yes, this is FAA Approved under FAA TSO-C71.

Does the True Blue Dual USB Charging Port include an installation kit?

Per the supplier: This unit does not come with an installation kit. Only comes with 2 screws and connector.

Can this be installed in a certified aircraft with only a TSO, or does it also require an STC with an AML. If so, is an AML available?

The TA102 is TSO'd for any aircraft. It is a technically defined as a minor alteration and can be installed on a log book entry for the installation. An STC with an AML is not needed.

Does the TRUE BLUE DUAL USB CHARGING PORT draw any power when nothing is plugged in?

The LED indicator light draws very minimal amperage even when nothing is charging.

Does the True Blue Dual charging port come with the connector kit?

Yes, the connector part number 9017960 is included with purchase.

What is the difference between the True Blue Dual USB charging port 10-32VDC, lighted unit and the True Blue Dual USB charging port, 10-32VDC, lighted, bottom connector?

Part number 11-13044 (6430102-3) has the wire connections to the rear of the unit where part number 11-13094 (6430102-4) has the wire connections from the bottom of the unit.

LOOKING FOR PART 6430102-1, this comes up on a search, but dont see that number on the page

Our Part# 11-12159 is Mid-Continent Part# 6430102-1. It is the first listed option in the ordering grid.
